Placa de baza GigaByte Z690 AORUS ULTRA
1 799.00 lei
cu TVA
Orderable quantity above the default stock is: 0
Solicita publicarea acestui produs in SICAP
Placa de baza GigaByte Z690 AORUS ULTRA
1 799.00 leiDescriere
Placa de baza Gigabyte Z690 AORUS ULTRA LGA 1700 CPU LGA1700 socket: Support for 12th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors L3 cache varies with CPU (Please refer to "CPU Support List" for more information.) Chipset Intel® Z690 Express Chipset Memory Support for DDR5 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz memory modules 4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel® HD Graphics support: 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.) Audio Realtek® ALC4080 CODEC Support for DTS:X® Ultra High Definition Audio 2-channel analog output Support for S/PDIF Out 7.1-channel digital signals * Actual output of digital signals may vary depending on the playback content and software used, and an external DAC is required. LAN Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) https://www.gigabyte.com/Motherboard/Z690-AORUS-ULTRA-rev-10/sp#sp
Specificatii
| Numar sloturi DDR5 |
4 x |
|---|---|
| Frecventa DDR5 |
6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz |
| Tehnologie Multi Channel DDR5 |
Dual Channel DDR5 Slots |
| Memorie DDR5 maxima |
128 GB |
| ID dataSPOT |
164073 |
| Model |
Z690 AORUS ULTRA |
| Producator |
GigaByte |
| Garantie comerciala |
3 ani |
Altele
| Alte detalii |
Bluetooth 5.2 |
|---|
Conectivitate
| Slot-uri PCI Express x16 |
3 x PCI Express x16 |
|---|---|
| PCI Express 2.0 |
PCI Express 5.0 |
| Serial ATA III with RAID Support |
6 x Serial ATA III with RAID Support |
| Porturi USB 2.0 |
8 x USB 2.0 |
| Porturi USB 3.2 |
10 + 2 type C x USB 3.2 |
Grafica
| CrossFire |
AMD Quad-GPU CrossFire. 2-Way AMD CrossFire |
|---|---|
| Video on-board |
Intel HD Graphics |
| DisplayPort |
1 |
Procesor
| Platforma |
Intel |
|---|---|
| Socket |
LGA 1700 |
| Procesoare compatibile |
12th Gen Intel Core. Pentium Gold and Celeron |
| North Bridge |
Intel Z690 |
Retea
| LAN on-board |
10 / 100 / 1000 / 2500 Mbit/s |
|---|---|
| Wireless |
802.11 a/b/g/n/ac/ax Mbit/s |
Specificatii fizice
| Format |
ATX |
|---|
Sunet
| Audio on-board |
7.1 |
|---|
Specificatii
- Platforma
- Intel
- Socket
- LGA 1700
- Procesoare compatibile
- 12th Gen Intel Core. Pentium Gold and Celeron
- North Bridge
- Intel Z690
- Numar sloturi DDR5
- 4 x
- Frecventa DDR5
- 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz
- Slot-uri PCI Express x16
- 3 x PCI Express x16
- Tehnologie Multi Channel DDR5
- Dual Channel DDR5 Slots
- Memorie DDR5 maxima
- 128 GB
- PCI Express 2.0
- PCI Express 5.0
- CrossFire
- AMD Quad-GPU CrossFire. 2-Way AMD CrossFire
- Serial ATA III with RAID Support
- 6 x Serial ATA III with RAID Support
- Video on-board
- Intel HD Graphics
- Audio on-board
- 7.1
- LAN on-board
- 10 / 100 / 1000 / 2500 Mbit/s
- Wireless
- 802.11 a/b/g/n/ac/ax Mbit/s
- Porturi USB 2.0
- 8 x USB 2.0
- Porturi USB 3.2
- 10 + 2 type C x USB 3.2
- DisplayPort
- 1
- Format
- ATX
- Alte detalii
- Bluetooth 5.2
- ID dataSPOT
- 164073
- Model
- Z690 AORUS ULTRA
- Producator
- GigaByte
- Garantie comerciala
- 3 ani
